PREPARATORY
Cooker
The objective of cooker conditioning is to obtain the best conditions prior to flaking.
Read More
PREPARATORY
Dryer Cooler
In case of a future expansion plan, the dryer cooler is advantageous as it has a modular type of construction that provides flexibility to increase capacity. The machine comes with one feed module and an unload one with additional intermediate modules for drying and cooling. Because of the aforementioned flexibility of its modular construction, drying or cooling modules can be increased in numbers. In order to increase efficiency, each module is sealed so that there is zero mixing of air. It also has a continuous chain with S.S or galvanised M.S trays to carry material. Every tenth tray has a heat resistant rubber scraper. These are meant for self-cleaning of fines that accumulate below on the return side of the chain and the bottom plate. Specially designed perforated trays are provided to give optimum area for flow of hot and cold air. At the same time, these trays help maintain air pressure and the required velocity. This helps clean the material accumulated between the carrying and returning sides of trays.
- It takes less downtime and the maintenance costs are also much lower.
- The design takes into consideration, long term maintenance.
- There in-built integral cooling options provided.
- The product boasts of great quality, stability, and higher efficiency.
- DRYER COOLER
- HOTAIR BLOWER-1
- HOTAIR BLOWER-2
- COLD AIR BLOWER-1
- COLD AIR BLOWER-2
- INDUCED DRAFTBLOWER-1
- INDUCED DRAFTBLOWER-2
- DROPPER CYCLONE-1
- DROPPER CYCLONE-2
- REDLER CONVEYOR TO EXTRACTOR
