CONTINUOUS DEODORIZATION

Refinery

CONTINUOUS DEODORIZATION

Deodorization is the final stage of the refining process, which is a steam distillation at elevated temperature under vacuum pressure to remove FFA, volatile compounds like oxidative compounds (aldehydes and ketones) and other contaminants based on their vapor pressure and volatility.

The current deodorization stage has three main concerns which are stripping of volatile components such as FFA and secondary oxidation products, removal of off-flavour, and thermal destruction of pigments. CONTINUOUS DEODORIZATION improves the flavour and oxidative stability of the refined oil by nearly a complete removal of FFA and other volatile odour and flavour compounds by thermal destruction of hydroperoxides. The peroxide value of oil is brought down to the minimum value possible in this process.

Ferro provides SS-316 and SS-304 ( as per customer requirement) vertical pressure vessel named FX-Deodorizer which is used to carry out the Deodorizing Process. It has 5-6 compartments/stages from top to bottom having various process friendly mechanisms within the compartments helping the efficient deodorization of bleached oil. With any heat introduced here, permanent damage is being done, which means the free fatty acids along with aldehydes, ketones, etc. in the oil are already quickly stripped off. The bottom compartment of deodorizer works as economiser in which the discharging oil is cooled by the incoming oil. Then this oil is passed through Polish filter and series of cooling heat exchangers to bring oil to atmospheric temperature.

In Ferro’s Deodorising section, the main equipments are Fx-Deodorizer vessel, Deaerator vessel, Thermic fluid heater system, Vacuum system, Steam PRS, Plate type heat exchangers, Polish filter, Cooling tower, etc along with various sub-parts like flowmeters, pumps, control valves, etc.

  • Excellent end result in terms of oil quality and testing parameters
  • Safe and Operator friendly automations
  • High quality products
  • Capacity of plant can be varied easily within a range by making minor changes in controls
  • Low maintenance with negligible breakdowns
  • Whole plant can be monitored in a single screen indicating temperature and levels and also many more detail of the equipments
  • All possible safety factors are considered while erection of plant
  • All vessels and equipments are well tested and certified
  1. DEODORISER
  2. FATTY-SCRUBBER
  3. POLISH FILTER
  4. PLATE TYPE HEAT EXCHANGER
  5. DOSING TANK
  6. VACUUM SYSTEM
  7. HOTWELL
